Large organizations may end up with siloed divisions whether its simply due to operating model or from acquisitions. In these environments divisions often have their own, independent view of a customer, but experiences increasingly need a more holistic view. The instinctive fix is to push identifiers into custom request headers or build a Backend for Frontend (BFF) layer per calling context — but both approaches collapse under domain complexity and become a maintenance burden at scale. Let’s walk through a pattern in Federated GraphQL schema design that addresses the root cause instead.

I’ll use a fictional CPG company to illustrate the pattern. This fictional company has three divisions: Food & Beverage, Personal Care, and Home & Cleaning. Each division manages customers independently with its own ID system. A single person might be a loyalty member for the food brand, a rewards participant for the beauty line, and a bulk buyer for the household products — all under different identifiers.

A person may have multiple IDs across divisions, but they’re the same customer.

Legacy Experiences

%%{init: {'themeVariables': { 'edgeLabelBackground': '#fff'}}}%%
flowchart LR
  classDef default fill:none,stroke-width:2px
  classDef grouping fill:none,stroke:#999,stroke-width:2px
  classDef user fill:none,stroke:#333,stroke-width:3px

  User([User])


  fbExp(Food & Bev
Experience)
  pcExp(Personal Care
Experience)
  hcExp(Home & Cleaning
Experience)


  subgraph Services
    fb[Food & Beverage]
    pc[Personal Care]
    hc[Home & Cleaning]
  end

  User --> fbExp
  User --> pcExp
  User --> hcExp
  fbExp -->|"Food & Beverage ID"| fb
  pcExp -->|"Personal Care ID"| pc
  hcExp -->|"Home & Cleaning ID"| hc

  class User user
  class Services grouping

Modern Experiences (What the People Want)

%%{init: {'themeVariables': { 'edgeLabelBackground': '#fff'}}}%%
flowchart LR
  classDef default fill:none,stroke-width:2px
  classDef grouping fill:none,stroke:#999,stroke-width:2px
  classDef user fill:none,stroke:#333,stroke-width:3px

  User([User])

  exp(Unified Experience)

  subgraph Services
    fb[Food & Beverage]
    pc[Personal Care]
    hc[Home & Cleaning]
  end

  User --> exp

  exp -->|"Food & Beverage ID"| fb
  exp -->|"Personal Care ID"| pc
  exp -->|"Home & Cleaning ID"| hc

  class User user
  class Experiences grouping
  class Services grouping

When you build a federated supergraph to unify these domains, you quickly run into two problems:

  1. Identifier mapping — different subgraphs need different IDs to resolve their data
  2. Auth vs. resource context — the logged-in user isn’t always the owner of the resource being queried

The CustomerIdentifiers pattern solves both.

The Problem

1. Identifier Complexity

In a federated system, subgraphs contribute fields to shared entities like a Customer type. But each division’s backend services expect their own identifier. Looking up food loyalty accounts needs one ID; checking personal care rewards needs another, etc.

A single id on the Customer entity isn’t enough. Each subgraph needs the right division-specific identifier to resolve its fields.

2. Auth Context vs. Resource Context

The logged-in user acting on a record isn’t always the owner of that record. A support agent might look up a customer’s profile using internal tooling — the agent’s auth token has nothing to do with the customer being queried.

Historically, APIs have coupled these together by stuffing identifiers into custom headers. We can do better.

The Pattern

The solution is a CustomerIdentifiers entity that abstracts the ID mapping logic into the schema itself. It’s owned by a central identity subgraph and contributed to by other subgraphs as needed.

Customer Identifiers Subgraph (mapping capability)

type Customer @key(fields: "id") {
  id: ID!
  identifiers: CustomerIdentifiers @inaccessible
}

# The customer identifiers resolver in this subgraph implements the
# mapping logic required to fetch division-specific identifiers
type CustomerIdentifiers @key(fields: "id") @inaccessible {
  id: ID!
  foodLoyaltyId: ID
  personalCareRewardsId: ID
  homeBulkBuyerId: ID
}

Food Loyalty Subgraph

Contributes the foodLoyaltyProgram property to the Customer entity requiring the foodLoyaltyId.

type Customer @key(fields: "id") {
  id: ID!
  identifiers: CustomerIdentifiers @external

  foodLoyaltyProgram: FoodLoyaltyProgram
    @requires(fields: "identifiers { foodLoyaltyId }")
}

type CustomerIdentifiers @key(fields: "id") @external {
  id: ID!
  foodLoyaltyId: ID
}

type FoodLoyaltyProgram @key(fields: "id") {
  id: ID!
  # ...
}

Personal Care Subgraph

Contributes the personalCareRewards property to the Customer entity requiring the personalCareRewardsId.

type Customer @key(fields: "id") {
  id: ID!
  identifiers: CustomerIdentifiers @external

  personalCareRewards: PersonalCareRewards
    @requires(fields: "identifiers { personalCareRewardsId }")
}

type CustomerIdentifiers @key(fields: "id") @external {
  id: ID!
  personalCareRewardsId: ID
}

type PersonalCareRewards @key(fields: "id") {
  id: ID!
  # ...
}

Home & Cleaning Subgraph

type Customer @key(fields: "id") {
  # identity fields...

  wholesaleDiscounts: [WholesaleDiscount!]!
    @requires(fields: "identifiers { homeBulkBuyerId }")
}

# ...

A few things to notice:

  • @inaccessible — the identifiers field can never be queried by API consumers. It’s purely a server-side linking construct. Clients are completely unaware it even exists.
  • Declarative — which subgraphs require which identifiers is visible in the schema, making it auditable during governance reviews.
  • Stateless — no encrypted headers or session state flowing between services. Given a customer ID, the router resolves the mappings on every request.

key insight:
By keeping identifiers in the schema rather than in headers or session state, we decouple the auth context from the resource context. The same subgraph resolvers work whether a customer is querying their own data or a support agent is looking someone up.

Two Entry Points with a Single Entity

The pattern supports multiple entry points into the graph without duplicating resolver logic:

type Query {
  # Customer-facing: uses the logged-in user's auth context
  me: Customer

  # associate targets customer using global member ID
  customerById(id: ID!): Customer
}

# ...

Both entry points return the same Customer entity. All downstream subgraphs that contribute to Customer work identically regardless of how the query started. No duplicate resolvers. No BFF-per-context.

A consumer query looks the same either way:

query Me {
  me {
    foodLoyaltyProgram {
      points
      tier
    }
    personalCareRewards {
      balance
      coupons
    }
    # ...
  }
}

query CustomerById {
  customerById(id: "123") {
    foodLoyaltyProgram {
      points
      tier
    }
    personalCareRewards {
      balance
      coupons
    }
    # ...
  }
}

The consumer is blissfully ignorant of the ID mapping happening server-side.

The Prop-Drilling Problem

The CustomerIdentifiers pattern works great for entities directly on Customer. But as your graph grows deeper, a new problem emerges: prop drilling.

Every nested entity that needs a division-specific identifier has to thread identifiers down from the root, level by level. The Customer subgraph starts knowing about domains it shouldn’t care about. For example, if we wanted to logically group all of the loyalty programs in the graph to stop our Customer type from growing into an infinite list of properties, we need to define the grouping type Programs with its own identifiers property in the Customer subgraph. And the problem only gets worse with deeper levels of nesting. On the other hand, nesting is what allows us to express relationship hierarchies in the graph — we don’t want to lose that.

# Customer Subgraph — now coupled to Programs just to pass identifiers
type Customer @key(fields: "id") {
  id: ID!
  identifiers: CustomerIdentifiers @inaccessible

  programs: Programs
}

type Programs @key(fields: "id") {
  id: ID!
  identifiers: CustomerIdentifiers! @inaccessible # threaded down
}

Every logical grouping in the graph needs this treatment. It breaks domain boundaries and becomes unsustainable.

The Solution: @context

Apollo Federation’s @context directive solves this elegantly. Instead of threading identifiers through every entity level, we capture it once in a named context and let downstream fields pull from it directly.

Here’s how the schemas change:

The Customer subgraph no longer knows about Programs.

# Customer Subgraph — clean, no knowledge of Programs
type Query {
  me: Customer
  customerById(id: ID!): Customer
}

type Customer @key(fields: "id") @context(name: "customerCtx") {
  id: ID!
  identifiers: CustomerIdentifiers @inaccessible
}

type CustomerIdentifiers @key(fields: "id") @inaccessible {
  id: ID!
  foodLoyaltyId: ID
  personalCareRewardsId: ID
  homeBulkBuyerId: ID
}

Each division subgraph declares the context once on Customer and pulls the identifier it needs directly from $customerCtx, regardless of nesting depth.

# Food & Beverage Subgraph — pulls from context, no prop drilling
type Customer @key(fields: "id") @context(name: "customerCtx") {
  id: ID!
  identifiers: CustomerIdentifiers! @external

  programs: Programs @shareable
}

type Programs @key(fields: "id") {
  id: ID!

  foodLoyalty(
    _foodLoyaltyId: ID
      @fromContext(fields: "$customerCtx { identifiers { foodLoyaltyId } }")
  ): FoodLoyaltyProgram
}

type FoodLoyaltyProgram {
  id: ID!
  points: Int
  tier: String
  favoriteProducts: [String!]
}

type CustomerIdentifiers @key(fields: "id") @external {
  id: ID!
  foodLoyaltyId: ID
}

# Personal Care Subgraph — same pattern, different identifier
type Customer @key(fields: "id") @context(name: "customerCtx") {
  id: ID!
  identifiers: CustomerIdentifiers! @external

  programs: Programs @shareable
}

type Programs @key(fields: "id") {
  id: ID!

  personalCareRewards(
    _personalCareRewardsId: ID
      @fromContext(
        fields: "$customerCtx { identifiers { personalCareRewardsId } }"
      )
  ): PersonalCareRewards
}

type PersonalCareRewards {
  id: ID!
  balance: Float
  coupons: [String!]
  beautyProfile: String
}

type CustomerIdentifiers @key(fields: "id") @external {
  id: ID!
  personalCareRewardsId: ID
}

And our queries express the logical relationships we expect out the graph. Behind the scenes, Router generates an efficient query plan that fetches all required identifiers in a single request and fans out to the division subgraphs in parallel.

query Me {
  me {
    programs {
      foodLoyalty {
        points
        tier
      }
      personalCareRewards {
        balance
        coupons
      }
    }
    # other logical groupings of data ...
    profile {
      name
    }
  }
}

Why This Matters

The CustomerIdentifiers pattern, combined with @context, gives you:

  • A single entity for a holistic customer view, with ID mapping hidden from consumers
  • Decoupled auth and resource context — the same resolvers work for self-service and agent-assisted flows
  • Clean domain boundaries — no prop drilling, no cross-domain coupling in subgraph schemas
  • Auditability — every identifier dependency is declared in the schema, visible during governance reviews
  • Future-proofing — change the underlying ID systems without touching consumer APIs

Our fictional CPG company can now ship a single loyalty query that works identically whether a customer is checking their own rewards or a support agent is looking them up — no custom headers, no BFF-per-context, and no leaking of internal ID systems to consumers.

Large organizations don’t need to choose between unified experiences and domain autonomy. GraphQL Federation gives you both — if you design the schemas right.
